Description

BK150 Handheld Urine Analyzer

The BK150 Handheld Urine Analyzer combines portability with professional-grade performance, empowering healthcare providers to conduct rapid urinalysis anywhere. Its lightweight design and robust build make it perfect for point-of-care settings—from clinics and nursing stations to home visits and mobile health units. With intuitive operation, onboard data storage, and seamless connectivity, it streamlines workflows and enhances diagnostic accuracy.

Key Features

• Rapid analysis: complete 10-parameter test in under 60 seconds

• Touchscreen interface: 3.5-inch LCD for easy operation and result review

• Built-in thermal printer: instant hard copy of results for patient records

• Rechargeable lithium-ion battery: up to 200 tests on a single charge

• Compact & lightweight: under 350 g for true portability

• Data management: stores up to 5,000 records with date/time stamps

• Connectivity: USB and Bluetooth for exporting data to EMR systems

• Automatic calibration: ensures accurate readings with minimal maintenance

• Durable housing: splash-proof (IP54) for reliable field use

Technical Specifications

• Model: BK150

• Parameters measured: Glucose, Bilirubin, Ketone, Specific Gravity, Blood, pH, Protein, Urobilinogen, Nitrite, Leukocytes

• Test method: reflectance photometry

• Strip capacity: accepts standard 10-parameter urine test strips

• Display: 3.5-inch color TFT touchscreen

• Printer: built-in thermal, 12-dot/mm resolution

• Memory: 5,000 test records with patient ID, date, and time

• Connectivity: USB-C port, Bluetooth 4.0

• Power: rechargeable 3.7 V/2,000 mAh lithium battery

• Dimensions: 150 × 75 × 35 mm

• Weight: 340 g (with battery)

• Operating conditions: 10–40 °C, ≤85% RH

• Storage conditions: 0–50 °C, ≤85% RH

• Certifications: CE, ISO 13485, RoHS

How It Works

1. Insert a 10-parameter test strip into the strip port until it stops.

2. Apply 2 drops of fresh urine to the test areas on the strip.

3. The analyzer automatically initiates timing and measurement.

4. Results appear on screen in under 60 seconds.

5. Print results via the onboard printer or export electronically via USB/Bluetooth.

6. Store patient ID and test data automatically in device memory.

Benefits

• Point-of-Care Efficiency Eliminate delays by testing at bedside or in the field, reducing patient wait times and improving care delivery.

• Enhanced Accuracy Reflectance photometry and automatic calibration minimize user error and ensure consistent, reliable results.

• Streamlined Workflow Integrated printer and digital export simplify record-keeping and integration with electronic medical records.

• Cost Savings Rechargeable battery and low per-test strip cost deliver a low total cost of ownership.

• Versatile Application Ideal for clinics, hospitals, dialysis centers, nursing homes, sports medicine, and home health services.

Maintenance and Calibration

• Daily self-check: run built-in calibration strip to verify accuracy

• Clean strip port monthly with isopropyl alcohol swab

• Replace thermal printer paper roll as needed

• Charge battery after each session; avoid complete depletion

• For full service and calibration support, visit our support page: Contact Support

Warranty and Support

• One-year manufacturer’s warranty covering defects in materials and workmanship

• Extended warranty options available through our service plans

• CE and ISO 13485 certified for medical device safety and quality

Frequently Asked Questions

Q: Can I use third-party urine strips
A: The BK150 is calibrated for standard 10-parameter strips from approved suppliers. Using non-calibrated strips may affect accuracy.

Q: How do I export data to my EMR
A: Connect via USB-C cable or pair with Bluetooth to transfer CSV files to any compatible system.

Q: Is user training required
A: The intuitive touchscreen interface requires minimal training. Detailed user manual and online tutorials are available.
