Description

Modi Windsor Ceiling Fan

The Modi Windsor Ceiling Fan combines modern aesthetics with top-tier performance to keep your spaces cool and comfortable. Its 60-inch sweep and three precision-engineered blades move large volumes of air at low energy consumption. With multiple speed settings, reversible airflow, and a silent motor, this fan adapts to every season and décor style. Choose between a flush-mount kit for low ceilings or a downrod for high rooms. Whether in a home, office, or hospitality setting, the Windsor fan delivers consistent comfort and reliability.

Key Features

• 60-inch blade span for maximum air circulation

• Three aerodynamically-shaped ABS blades for smooth, even airflow

• Powerful AC motor drawing only 45 W at top speed

• Up to 4 200 CFM airflow for rapid cooling

• Three forward and three reverse speed settings to suit all seasons

• Whisper-quiet operation for disturbance-free comfort

• Flush-mount and downrod installation options for any ceiling height

• Durable powder-coated finish in classic white to resist corrosion

• Pull-chain control and optional wall-switch or remote control compatibility

Technical Specifications

• Model Number: MD-WF60

• Blade Material: High-density ABS plastic

• Motor Type: Single-phase AC induction motor

• Power Consumption: 45 W at maximum setting

• Airflow: 4 200 CFM (cubic feet per minute)

• Speeds: Six total (three forward, three reverse)

• Mounting Options: Flush mount (included), 4-inch downrod (optional)

• Control Method: Pull chains; compatible with wall switch or universal remote

• Noise Level: ≤ 50 dB at high speed

• Voltage: AC 220–240 V, 50 Hz

• Dimensions: 60 inch diameter, 14 inch total height (flush), 20 inch height (with downrod)

• Weight: 5.8 kg

• Certifications: CE, RoHS, SAA

Installation Guide

Follow these steps for safe, professional installation:

• Switch off mains power at the breaker box

• Assemble blades onto the motor housing using the provided screws

• Choose mounting method: • Flush-mount: attach canopy directly to ceiling bracket • Downrod: insert fan motor onto downrod, secure set-screw and cotter pin

• Connect wiring: live to live (L), neutral to neutral (N), earth to ground

• Secure canopy to mounting bracket and tighten all screws

• Install blades and tighten blade brackets evenly

• Restore power and test all speed settings and reverse function

For detailed wiring diagrams and troubleshooting tips visit our Electrical Supplies page.

Seasonal Benefits

Forward rotation (counterclockwise) pushes cool air down during warm months to enhance comfort and reduce air-conditioning load.

Reverse rotation (clockwise) draws cool air upward in cooler months, circulating warm air trapped at ceiling level for energy savings.

Use the reversible feature to maintain a balanced room temperature year-round and lower heating or cooling costs.

Energy Efficiency & Performance

• High-efficiency AC motor uses only 45 W, saving up to 75 percent compared to traditional ceiling fans.

• Aerodynamic blade design maximizes airflow while minimizing noise and power draw.

• Rated airflow of 4 200 CFM moves air across large spaces quickly for faster temperature regulation.

• Compatible with most universal fan remotes for programmable timers and smart home integration.

Maintenance Tips

• Clean blades and housing with a soft, damp cloth every three months to prevent dust buildup.

• Check blade alignment and tighten mounting screws annually to avoid wobble.

• Lubricate bearings every two years if the motor shows signs of friction noise.

• Inspect pull chains or remote receiver for wear and replace worn components promptly.

• For service or replacement parts visit our Contact Support page.

Warranty & Compliance

• Three-year manufacturer’s warranty on motor and components

• CE certified for electrical safety and performance

• RoHS compliant—free from hazardous substances

• SAA approved for use in Australian and New Zealand markets

Frequently Asked Questions

Q: What ceiling heights work best with this fan
A: The flush-mount kit suits ceilings down to 7 feet. For ceilings over 10 feet, use the optional downrod for optimal air movement.

Q: Is the fan remote included
A: The standard kit includes pull-chain control. A universal fan remote is available separately or as an add-on.

Q: Can I install multiple fans on one circuit
A: Yes. Ensure total circuit load does not exceed 80 percent of breaker capacity. Refer to local electrical codes.

Q: How do I reverse the blade direction
A: Use the slide switch on the motor housing to toggle between forward and reverse rotation.
